Product Detail
|
Key Features |
Applications |
|
High Power Handling |
Fiber Lasers |
|
Low Insertion Loss |
Fiber Optic Instruments |
Specifications
Parameter
Unit
Value
Center Wavelength (λc)
nm
1064 nm or specify
Typ. Peak Isolation
dB
35
Min. Isolation @ λc All Polarization States, 23 ℃
dB
28
Max. Insertion Loss @ λc, 23 ℃
dB
0.5
Max. Polarization Dependent Loss
dB
0.1
M2 Degradation
%
< 10
Beam Roundness
%
> 90
Min. Return Loss
dB
50
Max. Average Optical Power
W
20
Max. Peak Power (Pulse Width, 10 ns)
kW
10
Max. Tensile Load
N
5
Fiber Type (Input Port)
-
Specified by ordering info
Fiber Type (Output Port)
-
Free Space
Nominal Output Beam Diameter (1/e2)
mm
7 ± 0.5
Operating Temperature
℃
+ 10 to + 50
Storage Temperature
℃
0 to + 60
