Polarization Maintaining RGB Combiner

The PM RGB Combiner enables three primary colors in the visible wavelength region to be combined. The PM Combiner is based on environmentally stable thin film filter technology and is characterized with high extinction ratio, low insertion loss, and high return loss.

Inquiry now Download

Product Detail

Key Features	Applications
High Extinction Ratio	Fiber Optic Instruments
Low Insertion Loss

Specifications

Parameter		Unit	Value
Operating Wavelength (λc)		nm	635 (R), 532 (G), 488 (B)
Max. Insertion Loss	R-C	dB	4.0
	G-C	dB	3.5
	B-C	dB	3.5
Min. Extinction Ratio, 23 ℃	R-C	dB	16
	G-C	dB	16
	B-C	dB	17
Fiber Type	G, B & C Port	-	PM460-HP Fiber
	R Port	-	PM630-HP Fiber
Max. Optical Power (Continuous Wave)		mW	100
Operating Temperature		℃	+ 25 to + 45
Storage Temperature		℃	0 to + 75

¹IL is 1.5 dB higher, RL is 5 dB lower, ER is 2 dB lower for each connector added. Connector key is aligned to slow axis.
²The optical power handling is up to 50 mW for connectorized version.
