Product Detail
Specifications |
|||
Parameter |
Unit |
Type A |
Type B |
Center Wavelength (λc) |
nm |
1064 |
|
Typ. Insertion Loss, λc, 23 ℃ |
dB |
3.4 |
1.8 |
Max. Insertion Loss, λc, all temperature |
dB |
4.0 |
2.1 |
Typ. Isolation, λc, 23 ℃ |
dB |
52 |
30 |
Min. Isolation, λc, 23 ℃ |
dB |
45 |
25 |
Min. Extinction Ratio |
dB |
20 |
|
Min. Crosstalk |
dB |
50 |
|
Min. Return Loss |
dB |
50 |
|
Max. Optical Power (Continuous Wave) |
mW |
300 |
|
Fiber Type |
- |
PM 980 Panda fiber |
|
Max. Tensile Load |
N |
5 |
|
Operating Temperature |
℃ |
- 5 to + 50 |
|
Storage Temperature |
℃ |
- 40 to + 85 |
