The (6+1)×1 High Power Combiner with ClearCut Fiber Bragg Grating enables highly efficient combining of the powers from up to 6 multimode pump diodes into an FBG with low insertion loss for high power fiber lasers. With AFR's ClearCut design and packaging, the devices can handle 3 kW pump power and 3 kW signal power.
The Dual Polarization Beam Combiner/Splitter, 2 × 2 PBC/PBS, is a compact high performance lightwave component that combines or divides two orthogonal polarization signals into one or two output fibers. The most common applications are in polarization mode dispersion compensator, EDFA, Raman Amplifier, coherent telecommunication systems and fiber sensor. The Dual Polarization Beam Combiner/Splitter is characterized with high extinction ratio and low insertion loss.
The Faraday Mirror is a passive device that provides 90 degree rotation regarding the polarization state of the input light. The FM offers excellent performance including the lowest possible insertion loss and environmental stability. It is used in EDFAs, fiber lasers and fiber instruments to minimize the polarization effect.
The Red, Green, Blue Combiner enables three primary colors in the visible wavelength region to be combined. The combiner offers very low insertion loss and excellent environmental stability.
The Fiber Pigtailed Photodiode Array (FPDA) is a compact, multi-channel power-detecting device. It obviously simplifies module design and assembling process by pre-integrating several single power detectors in one package. It features with standard pins with 2.54 mm space that easily mount on PCB. It applies for channel power monitoring in DWDM system, in-line optical network switching protection monitoring (OLP), reconfigurable optical add/drop multiplexers (ROADM), and gain/attenuation monitoring in network's power detection.
