Product Detail
The PM Patchcord series has excellent enviromental stability, high return loss, low insertion loss. It is ideal for PM amplifiers, fiber lasers and test instrumentation applications.
|
Specifications |
|||
|
Parameter |
Unit |
Value |
|
|
Connector Type |
- |
UPC |
APC |
|
Wavelength |
nm |
1950 |
2000 |
|
Typ. Insertion Loss |
dB |
0.30 |
0.40 |
|
Max. Insertion Loss |
dB |
0.50 |
|
|
Min. Return Loss |
dB |
50 |
60 |
|
Min. Extinction Ratio |
dB |
23 |
|
|
Max. Optical Power (Continuous Wave) |
mW |
300 |
|
|
Fiber Length Tolerance |
% |
± 10 or specified |
|
|
Operating Temperature |
℃ |
- 5 to + 70 |
|
|
Storage Temperature |
℃ |
- 40 to + 85 |
|
