2 μm Connector/Patchcord

The single mode Patchcord series has excellent environmental stability, high return loss, low insertion loss and low polarization dependence. It is ideal for fiber lasers and test instrumentation applicatio.
  • Product Detail

Key Features Applications
Excellent Enviromental Stability Fiber Laser
Low Insertion Loss Test Instrumentation
High Return Loss


Specifications







 Parameter

Unit

Value

 Connector Type

-

UPC

APC

 Wavelength

nm

1950, 2000

 Typ. Insertion Loss

dB

0.30

0.40

 Max. Insertion Loss

dB

0.50

 Min. Return Loss

dB

50

60

 Max. Optical Power (Continuous Wave)

mW

300

 Fiber Length Tolerance

%

± 10 or specify

 Operating Temperature

- 5 to + 70

 Storage Temperature

- 40 to + 85
