| Key Features | Applications |
| QSFP Form Factor | Long Haul System |
| 1625/1550 nm WDM Filter Integrated | Datacenter Interconnect System |
| 1625 nm LD and APD Integrated |
Parameter | Unit | Value |
Operation Wavelength | nm | 1625 |
Pulse Width | ns | 10 to 20000 |
Dynamic Range (SNR = 1) | dB | 25 |
Attenuation Dead Zone | m | 10 |
Event Dead Zone | m | 3 |
Sampling Resolution | m | 0.8 |
Sampling Point | - | 128000 |
Distance Measurement Accuracy | m | ± (1 + Measurement distance x 10–4 + sampling resolution) |
Operating Case Temperature | ℃ | - 5 to + 70 |
Storage Temperature | ℃ | - 40 to + 85 |
Working Voltage Range | V | 3.13 to 3.46 |
Max. Power Dissipation | W | 3 |
