Channel

-

4 Ch.

8 Ch.

16 Ch.

4 Ch.

8 Ch.

16 Ch.

 Filter Type

nm

100 GHz

200 GHz

 Pass Bandwidth @ 0.5 dB

nm

0.22

0.5

 Max. Insertion Loss

dB

2.5

3.5

4.8

2.2

3.3

4.6

 Passband Flatness

dB

1.0

 Channel Uniformity

dB

1.5

 Channel Isolation (Mux)

dB

N/A

 Channel Isolation (Demux)

dB

25

 Max. Polarization Dependent Loss

dB

0.1

 Max. Polarization Mode Dispersion

ps

0.1

 Directivity

dB

55

 Min. Return Loss

dB

45

 Center Wavelength Stability

nm/℃

0.002

 Thermal Stability

dB/℃

0.006

 Max. Optical Power

mW

300

 Tensile Load

N

5

 Fiber Type

-

SMF-28 Fiber

 Operating Temperature

℃

- 5 to + 70

 Storage Temperature

℃

- 40 to + 85

 Package Dimensions

mm

100 × 80 × 9.5 (4 Ch.), 133 × 95 × 9.5 (8 Ch.), 150 × 115 × 14 (16 Ch.)
