| Key Features | Applications |
| QSFP-DD Form Factor | DWDM System |
| Full C-Band Gain Flatness | Datacenter Interconnect System |
| Transient Controlling | |
| Variable Output Power Setting |
Parameter | Unit | Value |
Operating Wavelength Range | nm | 1528.38 to 1566.72 |
Channel Number | - | 1 to 96 |
Input Power Range | dBm | - 20 to 2 |
Output Power Range | dBm | - 5 to 17 |
Min. Input Optical Power Shutdown | dBm | - 30 |
Output Power Variation | dB | ± 0.5 |
Fixed Gain | dB | 15 |
Gain Flatness | dB | 1.5 |
Gain Accuracy | dB | ± 0.5 |
Max. Noise Figure | dB | 6.7 |
Max. Return Loss | dB | 40 |
Max. VOA Attenuation | dB | 30 |
Max. Polarization Dependent Gain | dB | 0.5 |
Max. Polarization Mode Dispersion | ps | 0.5 |
Max. Transient Undershoot/Overshoot (100 μs event) | dB | 1.5 |
Max. Transient Setting Time | ms | 2 |
Operating Case Temperature | ℃ | - 5 to + 70 |
Storage Temperature | ℃ | - 40 to + 85 |
Working Voltage Range | V | 3.13 to 3.46 |
Max. Power Dissipation | W | 4 |
