| Key Features | Applications |
| QSFP Form Factor | Optical Power Monitoring of DWDM System |
| 50 GHz and 100 GHz Channel Spacing Available |
Parameter | Unit | Value |
Channel Center Frequency Range | THz | 191.35 to 196 |
Absolute Channel Center Frequency Accuracy | GHz | ± 4 |
Configurable Channel Bandwidth | GHz | 50 or 100 |
Max. Total Optical Input Power | dBm | 24 |
Channel Input Power Range | dBm | - 15 to 15 |
Input Coupler Ratio | % | 5/95 |
Max. Insertion Loss | dB | 1 |
Max. Channel Power Difference (50 GHz) | dB | 12 |
Max. Channel Power Difference (100 GHz) | dB | 15 |
Channel Power Accuracy | dB | ± 1.2 |
Max. Noise Floor | dBm | -20 |
Polarization Dependent Power Accuracy | dB | ± 0.5 |
Max. Channel Power Repeatability | dB | 0.5 |
Operating Case Temperature | ℃ | - 5 to + 50 |
Storage Temperature | ℃ | - 40 to + 85 |
Working Voltage Range | V | 3.13 to 3.46 |
Max. Power Dissipation | W | 6.5 |
