| Key Features | Applications |
| Ultra-Low Insertion Loss, Typical < 0.3 dB per Channel | Data Center Applications for 1.6T |
| Sub-Micron Alignment Accuracy, OE LENS Based Positioning | |
| Customizable Fiber Length and Connector Options |
| Parameter | Unit | Value |
| Wavelength | nm | 1310 |
| Channel Count | 16 | |
| Typ. Insertion Loss | dB | 0.3 |
| Max. Insertion Loss | dB | 0.35 |
| Max. Pitch Error | μm | 5 |
| Fiber Length Tolerance | % | ± 0.3 or Specify |
| Operating Temperature | ℃ | - 5 to + 70 |
| Storage Temperature | ℃ | - 40 to + 85 |
