Key Features | Applications |
Low Error Function | EDFA |
Low Insertion Loss | Raman Amplifier |
Parameter | Unit | Value |
Wavelength Range | nm | As filter spec |
Max. Peak Insertion Loss | dB | 0.6 |
Typ. Peak Insertion Loss | dB | 0.4 |
Peak to Peak in Error Function, 23 ℃ | dB | 0.5 |
Wavelength Thermal Drift | nm/℃ | ≤ 0.002 |
Min. Return Loss | dB | 50 |
Max. Polarization Dependent Loss | dB | 0.1 |
Polarization Mode Dispersion | ps | 0.1 |
Max. Optical Power (Continuous Wave) | mW | 300 |
Max. Tensile Load | N | 5 |
Fiber Type | - | SMF-28 Fiber |
Operating Temperature | ℃ | - 5 to + 70 |
Storage Temperature | ℃ | - 40 to + 85 |
1IL is 0.3 dB higher, RL is 5 dB lower for each connector added.
