| Key Features | Applications |
| High Responsivity | Optical Sensing System |
| Low Dark Current |
Parameter | Unit | Value |
Center Wavelength (λc) | nm | 2000 |
Operating Wavelength Range | nm | λc ± 40 |
Min. Responsivity | A/W | 0.8 |
Min. Return Loss1 | dB | 40 |
Max. Reverse Voltage (VR) | V | 1 |
Max. Input Power | mW | 10 |
Typical Bandwidth (RL = 50 Ω, VR = 0 V) | MHz | 90 |
Max. Dark Current (VR = 0.5 V @ 70 ℃) | uA | 1 |
Max. Capacitance (VR = 0 V, f = 1 MHz) | pF | 50 |
Fiber Type | - | SMF-28 Fiber |
Operating Temperature | ℃ | 0 to + 70 |
Storage Temperature | ℃ | - 40 to + 85 |
Soldering Temperature (over 2 mm from head, less than 5s) | ℃ | ≤ 260 |
