| Key Features | Applications |
| High Isolation | Laser Chip |
| Low Insertion Loss |
| Parameter | Unit | Value | ||
| Stage | — | Single Stage | Dual Stage | |
| Center Wavelength (λc) | nm | 1310 or 1550 | ||
| Typ. Insertion Loss | dB | 0.12 | 0.2 | |
| Max. Insertion Loss | dB | 0.3 | 0.5 | |
| Peak Isolation | dB | 40 | 55 | |
| Min. Isolation, 23 °C | dB | 30 | 40 | |
| Clear Aperture | mm | 0.4 - 0.9 | ||
| Max. Optical Power (Continuous Wave) | mW | 300 | ||
| Polarization Plane of Input | — | Indicated in Package Diagram | ||
| Tilt Angle of Input Plane | degree | 4,6 | ||
| Operating Temperature | °C | 0 to +60 | ||
| Storage Temperature | °C | - 40 to +85 | ||
