Key Features | Applications |
High Isolation | Laser Chip |
Low Insertion Loss |
|
Parameter | Unit | Value | |
Stage | - | Single Stage | Dual Stage |
Center Wavelength (λc) | nm | 1310 or 1550 | |
Typ. Insertion Loss | dB | 0.1 | 0.2 |
Max. Insertion Loss | dB | 0.2 | 0.3 |
Peak Isolation | dB | 42 | 55 |
Min. Isolation, λc ± 15 nm, 23 ℃ | dB | 30 | 40 |
Clear Aperture | mm | 0.9 | |
Max. Optical Power (Continuous Wave) | mW | 300 | |
Polarization Plane of Input | - | Indicated in package diagram | |
Tilt Angle of Input Polarization | degree | 0 or specify | |
Operating Temperature | ℃ | 0 to + 60 | |
Storage Temperature | ℃ | - 40 to + 85 | |
