| Key Features | Applications |
| High Power Handling | Fiber Laser |
| Low Insertion Loss | Fiber Optic Instruments |
Parameter | Unit | Value |
Center Wavelength (λc) | nm | 2000 |
Operating Wavelength Range | nm | λc ± 30 |
Output Beam Diameter | mm | 4.9 ± 0.5 |
Extinction Ratio (PM Type Only, Both Axes Are Working) | dB | 20 |
Max. Insertion Loss | dB | 0.5 |
Min. Isolation @ λc, 23 ℃ | dB | 35 |
Max. Average Optical Power | W | 5 |
Max. Peak Power (Pulse Width, 10 ns) | kW | 10 |
Return Loss | dB | 45 |
Fiber Type | - | SMF-28 or PM 1550 Fiber |
Operating Temperature Range | ℃ | + 10 to + 60 |
Storage Temperature | ℃ | - 40 to + 85 |
