1310/1480/1550 nm Filter WDM

1310/1480/1550 nm Filter WDM

The Filter Wavelength Division Multiplexer is based on environmentally stable thin film filter technology. The devices combine or separate light at different wavelengths in a wide wavelength range. They offer very low insertion loss, low polarization dependence, high isolation and excellent environmental stability. High power handling capability can be achieved through unique pigtail processing and high quality AR coating. These components have been extensively used in EDFAs, Raman amplifiers, WDM networks and fiber optical instruments.
Product Detail

Key Features

Applications

Low Polarization Dependent Loss

EDFA

Low Insertion Loss

Raman Amplifier

High Isolation

Fiber Optic Instruments

Specifications
ParameterUnitValue
Pass Band                       Wavelength Rangenm1270 - 13501450 - 14901500 - 1520


(1530 - 1600)(1530 - 1580)(1530 - 1570)
                                        Typ. Insertion LossdB0.40.40.5
                                        Max. Insertion LossdB0.60.60.7
                                        Typ. IsolationdB353035
                                        Min. IsolationdB302530
Reflection Band              Wavelength Rangenm1530 - 16001530 - 15801530 - 1570


(1270 - 1350)(1450 - 1490)(1500 - 1520)
                                        Typ. Insertion LossdB0.3
                                        Max. Insertion LossdB0.5
                                        Typ. IsolationdB15
                                        Min. IsolationdB12
Min. Return LossdB50
Max. Polarization Dependent Loss  dB0.1
Typ. Polarization Dependent Loss  dB0.05
Thermal StabilitydB/℃0.005
Max. Optical PowermW300
Max. Tensile LoadN5
Fiber Type-SMF-28
Operating Temperature  ℃- 5 to + 70
Storage Temperature℃- 40 to + 85


1IL is 0.3 dB higher, RL is 5 dB lower for each connector added.
