Key Features | Applications |
High Extinction Ratio | Fiber Lasers |
Low Insertion Loss | Amplifiers |
High Isolation | Instrumentation |
| Parameter | Unit | Value | |||
| Stage | - | Single Stage | Dual Stage | ||
| Grade | - | Grade P | Grade A | Grade P | Grade A |
| Center Wavelength (λc) | nm | 1064 | |||
| Typ. Peak Isolation | dB | 38 | 36 | 55 | 52 |
| ³Min. Isolation, λc, 23 ℃, ≤ 30 mW | dB | 35 | 32 | 45 | 42 |
| Typ. Insertion Loss, λc | dB | 1.5 | 1.6 | 2.4 | 2.6 |
| Max. Insertion Loss, λc | dB | 2 | 2.2 | 3.4 | 3.6 |
| Min. Extinction Ratio, 23 ℃ | dB | 20 | 18 | 20 | 18 |
| Min. Return Loss (Input/Output) | dB | 55/50 | 55/50 | 55/50 | 55/50 |
| Max. Average Optical Power | mW | 300 | |||
| Max. Peak Power for ns Pulse | kW | 10 | |||
| Max. Tensile Load | N | 5 | |||
| Fiber Type | - | PM 980 Panda Fiber | |||
| Operating Temperature | ℃ | - 5 to + 50 | |||
| Storage Temperature | ℃ | - 40 to + 85 | |||
¹IL is 0.5 dB higher, RL is 5 dB lower, and ER is 2 dB lower for each connector added.
²Connector key is aligned to slow axis.
³The isolation is related to the input power. Please inform us when you need high isolation and operate above 30 mW.
