| Key Features | Applications |
| QSFP‑DD Form Factor | DWDM System |
| Dual Channel Amplifier | Data Center Interconnect System |
| Transient Controlling | |
| Variable Output power Setting |
| Parameter | Unit | Value |
| Operating Wavelength Range | nm | 1535 to 1561 |
| Input Power Range | dBm | - 20 to - 3 |
| Max. Output Power | dBm | 17 |
| Min. Input Optical Power Shutdown | dBm | - 30 |
| Output Power Variation | dB | ± 0.5 |
| Fixed Gain | dB | 20 |
| Gain Flatness | dB | 2 |
| Gain Accuracy | dB | ± 0.5 |
| Max. Noise Figure | dB | 6.5 |
| Max. Return Loss | dB | 40 |
| Max. VOA Attenuation | dB | 30 |
| Max. Transient Undershoot/Overshoot(100 μs event) | dB | 1.5 |
| Max. Transient Setting Time | ms | 2 |
| Max. Polarization Dependent Gain | dB | 0.5 |
| Max. Polarization Mode Dispersion | ps | 0.5 |
| Operating Case Temperature | ℃ | - 5 to + 70 |
| Storage Temperature | ℃ | - 40 to + 85 |
| Working Voltage Range | V | 3.13 to 3.46 |
| Max. Power Dissipation | W | 4 |
