Polarization Insensitive Optical Circulator (High Reliability)

Name: Polarization Insensitive Optical Circulator (High Reliability)
Rating: 4.5 (100 reviews)

The Optical Circulator is a compact, high performance lightwave component that routes incoming signals from Port 1 to Port 2, and incoming Port 2 signals to Port 3. The component provides high isolation, low insertion loss, low PDL, low PMD and excellent environmental stability.

Inquiry now Download

Product Detail

Key Features	Applications
Optical circulator	Submarine optical fiber communication
High Reliability

Specifications

Parameter	Unit	Value
Center Wavelength (λc)	nm	1550
Operating Wavelength Range	nm	1530 - 1565
P1-P2. Max.Insertion Loss, λc, 23 °C	dB	0.7
P2-P3, Max. Insertion Loss, - 5 to + 75 °C, 1530 - 1565 nm	dB	0.9
P2-P1, Min. Isolation, λc, 23 °C	dB	50
P3-P2, Min. Isolation, - 5 to + 75 °C, 1530 - 1565 nm	dB	40
Min. Crosstalk	dB	50
Min. Return Loss	dB	50
Max. Polarization Dependent Loss, - 5 to + 75 ℃ , 1530 - 1565 nm	dB	0.15
Max. Polarization Mode Dispersion	ps	0.1
Max. Optical Power	W	1
Max. Tensile Load	N	5
Fiber Type	-	SMF - 28 Ultra 200 kpsi fiber
Operating Temperature	°C	- 5 to + 75
Storage Temperature	°C	- 40 to + 85
