| Key Features | Applications |
| Excellent Enviromental Stability | Fiber Laser |
| Low Insertion Loss | Instrumentation Applications |
| High Return Loss | PM Amplifiers |
Parameter | Unit | Value | |
Connector Type | - | UPC | APC |
Wavelength | nm | 1950 , 2000 | |
Typ. Insertion Loss | dB | 0.30 | 0.40 |
Max. Insertion Loss | dB | 0.50 | |
Min. Return Loss | dB | 50 | 60 |
Min. Extinction Ratio | dB | 23 | |
Max. Optical Power (Continuous Wave) | mW | 300 | |
Fiber Length Tolerance | % | ± 10 or specify | |
Operating Temperature | ℃ | - 5 to + 70 | |
Storage Temperature | ℃ | - 40 to + 85 | |
