Key Features | Applications |
High Power Handling | Fiber Lasers |
Low Insertion Loss | Fiber Optic Instruments |
Parameter | Unit | Value |
Center Wavelength (λc) | nm | 1550 |
Max. Polarization Dependent Loss | dB | 0.15 |
Typ. Peak Isolation | dB | 35 |
Min. Isolation, λc, All Polarization States, 23 ℃ | dB | 28 |
Typ. Insertion Loss | dB | 0.35 |
Max. Insertion Loss, λc ± 20 nm, 23 ℃ | dB | 0.5 |
Min. Return Loss (Input/Output) | dB | 50/50 |
Max. Optical Power | W | 20 |
Max. Peak Power (Pulse Width,10 ns) | kW | 10 |
Max. Tensile Load | N | 5 |
Fiber Type | - | SMF-28 Fiber |
Operating Temperature | ℃ | + 10 to + 50 |
Storage Temperature | ℃ | 0 to + 60 |
1IL is 0.3 dB higher, RL is 5 dB lower and Optical Power is 1 W for each connector added.
