Operation Wavelength

nm

1080 ± 30

 Numerical Aperture (NA)

-

≤ 0.22

 Max. Transmission Loss of Fiber Core

%

2

 Max. Power Handling

kW

20

 Max. Peak Power

-

Max. 50 kW @ 1 ms

Max. 1 mW @ 50 ns

 Max. Stripping Cladding Power

-

1 kW for 10 min

 500 W Continuously

 Max. Z-Position Tolerance

μm

± 80

 Max. Angular Deviation

mrad

10

 Cooling Water Requirements

 Flow Rate

L/min

1.5 - 3

 Min. Water Pressure

Mpa

0.8

 Water Temperature

°C

10 - 45

 Water Hose Diameter

mm

ID/OD = 4/6

 Others

 Mechanical Interface

-

Compatible with the Standard QD Interface

 Type of Cable Gland

-

Metal

 Min. Fiber Tensile Load

N

5

 Operating Ambient Temperature

°C

+ 5 to + 50

 Storage Temperature

°C

- 20 to + 70

 Safety Interlock

 Interlock Circuit Resistance

-

3.3 kΩ ± 5 % + 2 Ω/m Fiber

 Thermoswitch Limit

-

70 °C ± 5 °C, Reset temp < 30 °C

 Max. Working Voltage

-

33 V
