| Key Features | Applications |
| Low Excess Loss | Space |
| High Reliability | Vacuum Application |
| Parameter | Unit | Value |
| Center Wavelength (λc) | nm | 1550 |
| Operating Wavelength | nm | λc ± 20 |
| Coupling Ratio | % | 0.1/99.9 |
| Max. Insertion Loss | dB | 30 ± 3/0.22 |
| Coupling Ratio | % | 20/80 |
| Max. Insertion Loss | dB | 7.7/1.3 |
| Max. Excess Loss | dB | 0.2 |
| Min. ER ¹ | dB | 20 |
| Max. Excess Loss for Each Connector | dB | 0.3 |
| Max. Optical Power (Continuous Wave) | W | 10 |
| Thermal Stability | dB/°C | ≤ 0.005 |
| Min. Return Loss | dB | 50 |
| Min. Directivity | dB | 50 |
| Fiber Type for Signal Port | - | PM1550 Panda Fiber |
| Fiber Type for Tap Port | - | PM fiber or Singlemode Fiber |
| Operating Temperature | °C | - 20 to + 70 |
| Storage Temperature | °C | - 40 to + 85 |
¹ ER data listed in the table are for the ports with coupling ratio greater than 10%. It will be 2 dB lower for a tap port with coupling ratio between 1 - 10%. For 1% tap port, ER is not considered.
² IL is 0.3dB higher, RL is 5 dB lower, ER is 2 dB lower for each connector added. Connector key is aligned to slow axis.
³ The Optical Power is 1 W only for connector added.
⁴ Data tested at central wavelength only.
