1310/1550 nm Mini Fiber Circulator

The Mini Fiber Optic Circulator is a compact, high performance lightwave component that routes incoming signals from Port 1 to Port 2, and incoming Port 2 signals to Port 3. The optical circulator provides high isolation, low insertion loss, low PDL, low PMD and excellent environmental stability. It is widely used in combination with fiber gratings and other reflective components in DWDM systems, high speed systems and bi-direction communication systems.

Inquiry now Download

Product Detail

Key Features	Applications
High Isolation	Denser Channel Plans
Low Insertion Loss	Access/Enterprise Networks
Compact Size	Fiber Sensing

Specifications

Parameter	Unit	Value
Center Wavelength (λc)	nm	1310 or 1550
Operating Wavelength Range	nm	λc ± 20
Transmitting Direction	-	1 → 2, 2 → 3, 3 → 4
Typ. Insertion Loss	dB	0.7
Max. Insertion Loss	dB	0.9
Min. Isolation, 23 ℃	dB	38
Min. Crosstalk	dB	50
Min. Return Loss	dB	50
Max. Polarization Dependent Loss, 23 ℃	dB	0.2
Max. Polarization Mode Dispersion	ps	0.1
Max. Optical Power (Continuous Wave)	mW	300
Max. Tensile Load	N	5
Fiber Type	-	SMF-28 Fiber
Operating Temperature	℃	0 to + 70
Storage Temperature	℃	- 40 to + 85
Package Dimensions	mm	5.5 × 40

¹IL is 0.3 dB higher and RL is 5 dB lower for each connector added.
