Key Features | Applications |
Low Insertion Loss | Fiber Lasers |
High Isolation | Instrumentation |
High Return Loss |
Parameter | Unit | Value |
Center Wavelength (λc) | nm | 1064 |
Operating Wavelength Range | nm | λc ± 10 |
Min. Isolation, All Polarization States, 23 ℃ | dB | 25 |
Typ. Insertion Loss, 23 ℃ | dB | 0.5 |
Max. Insertion Loss, 23 ℃ | dB | 0.8 |
Max. Polarization Dependent Loss | dB | 0.2 |
Min. Crosstalk | dB | 45 |
Min. Return Loss | dB | 45 |
Max. Average Optical Power | ||
Port 1 → Port 2 | W | 50 |
Port 2 → Port 3 | W | 10 |
Max. Peak Power (Pulse Width, 10 ns) | kW | 20 |
Max. Tensile Load | N | 5 |
Fiber Type | - | Specified by ordering info |
Operating Temperature | ℃ | + 10 to + 50 |
Storage Temperature | ℃ | 0 to + 60 |
