Key Features | Applications |
High Resolution | Fiber Sensing |
Compact Size | Equipment |
Fiber Optic Instruments |
Parameter | Unit | Value | |
Center Wavelength (λc) | nm | 780 or 850 | 980 or 1064 |
Operating Wavelength Range | nm | ± 10 | ± 20 |
Max. Excess Loss | dB | 1.0 | 0.6 |
Max. WDL, Minimum Attenuation, 23 ℃ | dB | 0.3 | |
Min. Attenuation Range | dB | 30 | |
Resolution within 10 dB Attenuation Range | dB | 0.1 | |
Min. Extinction Ratio (for PM Fiber Type), 23 ℃ | dB | 20 | |
Max. PDL (for SM Fiber Type), λc, Minimum Attenuation, 23 ℃ | dB | 0.05 | |
Max. TDL at attenuation range, λc2 | dB/℃ | 0.01 | |
Min. Return Loss (for SM or PM Fiber) | dB | 50 | |
Min. Return Loss (for MM Fiber) | dB | 25 | |
Max. Optical Power (Continuous Wave) | mW | 300 | |
Operating Temperature | ℃ | 0 to 70 | |
Storage Temperature | ℃ | - 40 to + 85 | |
1IL is 0.5 dB higher, RL is 5 dB lower, and ER is 2 dB lower for each connector added.
2TDL is exempted when attenuation value over 30 dB.
