| Key Features | Applications |
| High Power Handling | Fiber Optic Instruments |
| Parameter | Unit | Value |
| Center Wavelength (λc) | nm | 2000 |
| Max. Extinction Ratio | dB | 18 |
| Min. Isolation @ λc, 23 ℃ | dB | 40 |
| Max. Insertion Loss @ λc ± 20 nm, All Polarization States | dB | 1.6 |
| Min. Return Loss (Input/Output) | dB | 45 |
| Max. Average Optical Power | W | 20 |
| Max. Peak Power for ns Pulse | kW | 10 |
| Max. Tensile Load | N | 5 |
| Fiber Type | — | Specified by Ordering Info |
| Operating Temperature | ℃ | 10 to + 50 |
| Storage Temperature | ℃ | 0 to + 65 |
1IL is 0.3 dB higher, RL is 5 dB lower, and ER is 2 dB lower for each connector added.
2Optical Power is 1W only for connector added. Connector key is aligned to slow axis.
3The input light ER of the customer system needs to be greater than 16 dB.
